380V 50HZ Metal Wide Belt Sander Machine For Deburring / Slag Removal

  • 1
  • 2

Brand Name : SKD

Model Number : MS13RR

Place of Origin : China

Name : Metal Wide Belt Sander

Type : Sanding

Feature : Robust welded frame

Power : 380v 50Hz or customized

Table Lifting Motor : 1.5kw

Number of Heads : 2

MOQ : 1 set

Price : USD10000-350000

Packaging Details : Shrink Wrapped or Woodcase

Delivery Time : 20-60 days

Payment Terms : TT

Supply Ability : 70-100set per year

Contact Now

Metal Wide Belt Sander

General Description
This is a metalworking wide belt sander for deburring, sanding, polishing, finishing, slag removal and texturing.With 2 powerful sanding drums and vacuum sucking work-table, the metal wide belt sander can process wide metal sheets, plates,middle and small size metal work-piece in an effective way for deburring, grinding and finishing. With a quick change of the abrasive belt, this metal wide belt sander can do slag removal and oxide removal of the metal parts done by plasma cut or flame cut .
The metal wide belt sander is designed for one wide part or multi smaller parts processed in a production line or in an independent way. Vacuum sucking work-table can fix minimum 100mm smaller parts on the conveyor belt to insure a good deburring or finishing. Either high productivity in a flow line or reliable effects for smaller parts, this metal wide belt sander will not let you down, but saving labor and time.
SPECIFICATIONS

​

  1. Conveyor Drive Motor 5.5kw
  2. Feed Speed 5-25 meter per minute variable
  3. Dimension 2200x2500x2300mm WxDxH
  4. Weight 3.9 ton
  5. Work piece Max Width 1350mm
  6. Work piece Max Thickness 60mm
  7. Work piece Min. Length 100mm

380V 50HZ Metal Wide Belt Sander Machine For Deburring / Slag Removal380V 50HZ Metal Wide Belt Sander Machine For Deburring / Slag Removal
