MS13RR Precise Sanding Double Head Wide Belt Sander For Metal Finishing

Model Number : MS13RR

Place of Origin : China

Name : Metal Wide Belt Sander

Work Piece Max Thickness : 60mm

Work piece Max Width : 1350mm

Vacuum Area : 1250×200mm

Table Lifting Motor : 1.5kw

Number of Heads : 2

MOQ : 1 set

Price : USD10000-350000

Packaging Details : Shrink Wrapped or Woodcase

Delivery Time : 20-60 days

Payment Terms : TT

Supply Ability : 70-100set per year

Contact Now

Metal Wide Belt Sander With Control Panel And Motor Load Meter For Precise Sanding

General Description

This is a metalworking wide belt sander for deburring, sanding,polishing, finishing, slag removal and texturing. With 2 powerful sanding drums and vacuum sucking work-table, the metal wide belt sander can process wide metal sheets, plates, middle and small size metal work-piece in an effective way for deburring, grinding and finishing. With a quick change of the abrasive belt, this metal wide belt sander can do slag removal and oxide removal of the metal parts done by plasma cut or flame cut .

FEATURES

1350mm max working width
Digital thickness readout for conveyor height
Control panel with motor load meter, digital readout
Electronic abrasive belt tracking
Pneumatic abrasive tensioning
High quality contact drum
Robust welded frame

SPECIFICATIONS

Abrasive Belt Size 2500x1380mm
Motor : 22kw +22kwwith frequency control
Table Lifting Motor: 1.5kw
Number of Heads : 2
Sanding Drum Diameter: 240mm
Dust port size: drum 150mm x 6, space 100mm x 4
Automatic Thickness Control: Yes (Thickness or)
Foot Print: 51-1/2″ x 19″
